- Technical Specification
- Probes
17" HD LCD monitor, 10.4” touch screen, weight: 308lbs (140kg), 4 probe ports
Imaging Modes:
2D, M mode, M-color Flow Mode, Anatomical M-mode, Trapezoidal Mode, Color, Power Angio, Pulse Wave Doppler, Bi-directional Power (=HD FLOW), SCW Doppler, Tissue Doppler (Velocity) Imaging, Live 3D Echo, Stress Echo, Strain and Strain Rate (Cardiac), B Flow, Panoramic Imaging (=Logiq view), Contrast Imaging - Cardiac, Contrast Imaging - General Imaging
Applications:
Abdominal, OB, Fetal Echo, Vascular, TCD (Transcranial), Small Parts (Breast, Thyroid, Testis…), MSK/Anesthesiology, Pediatrics, Echocardiography Adult, Interventional Cardiology, Echocardiography Pediatric, Echocardiography Neonate, Stress Echocardiography, Transesophageal Echo Adult, Transesophageal Echo Pediatric, Internal Medicine w/ Shared Service, Surgery, Contrast Imaging - Cardiac (High or Low MI)
11L-D
Bandwidth: 5 - 12 MHz
Applications: Vascular, Breast, Small Parts, Musculoskeletal, Thyroid
12S-D
Bandwidth: 4 - 12 MHz
Applications: Pediatric, Cardiac, Coronary, Neonatal Head, Abdominal, Rodents
3V-D 4D
Bandwidth: 1.5 - 4.0 MHz
Applications: 3D, 4D, Abdominal, Cardiac, Transcranial Doppler
4C-D
Bandwidth: 1.6 - 6 MHz
Applications: Abdomen, Obstetrics, Gynecology, Urology, Peripheral Vascular
4V-D 4D
Bandwidth: 1.5 - 4 MHz
Applications: Cardiac, LVO Contrast, Stress, Fetal Heart
6S-D
Bandwidth: 2.7 - 8 MHz
Applications: Pediatric, Cardiac, Coronary, Neonatal Head, Abdominal, Fetal Heart
6Tc
Bandwidth: 3 - 8 MHz
Applications: Cardiac, Transesophageal
9L-D
Bandwidth: 2.4 - 10 MHz
Applications: Vascular, Musculoskeletal, Thyroid, Contrast
i13L
Bandwidth: 5.9 - 14.1 MHz
Applications: Cardiac, Rodents
M5S-D
Bandwidth: 1.5 - 4.5 MHz
Applications: Cardiac, Pediatrics, Abdomen, Fetal Heart, Transcranial, Coronary, LVO Contrast
